Wave Soldering Unloading Machine With Track YSU-350
Description：The Wave Soldering Unloading Machine With Track YSU-350 is developed to enhance automation and consistency after wave soldering. It provides controlled PCB transfer, ensuring smooth unloading while maintaining solder joint integrity. The track-based design allows precise alignment with existing production lines, supporting efficient process integration. Designed for continuous operation, the YSU-350 delivers stable performance during long production runs. Its adjustable configuration accommodates various board sizes and thicknesses, making it suitable for flexible manufacturing needs. By improving unloading efficiency and reducing manual intervention, the YSU-350 helps manufacturers achieve higher productivity and more predictable product quality.
Min Order Qty：1PC
Lead Time：15 Days
Introduction
The Wave Soldering Unloading Machine With Track YSU-350 is developed to enhance post-soldering automation and overall line efficiency. Positioned directly after the wave soldering process, it provides orderly and reliable PCB unloading, preventing congestion and reducing operator workload. The track-based transfer design ensures stable board movement, helping to protect solder joints and through-hole components during the critical post-soldering stage.
The YSU-350 is suitable for electronics manufacturers handling diverse product requirements. Its adjustable track width and transfer parameters allow it to support various board dimensions without compromising stability. This flexibility is particularly valuable in production environments with frequent model changeovers or mixed-product assembly. The machine’s precise and consistent unloading performance helps maintain a balanced production rhythm, even during long operating cycles.
From a production management perspective, the Wave Soldering Unloading Machine With Track YSU-350 plays a key role in improving workplace safety and process consistency. Automated unloading reduces direct contact with hot PCBs, lowering operational risk while improving ergonomics. By delivering boards in a controlled sequence to downstream processes, the system enhances inspection efficiency and overall line organization, supporting higher-quality output and predictable manufacturing results.
Wave Soldering Unloading Machine With Track YSU-350 Applied in Smart Home Appliance Electronics Factories
- Reliable Unloading for High-Mix Appliance Production
The SMT Wave Soldering Unloading Machine With Track YSU-350 efficiently unloads wave-soldered PCBs in smart appliance factories with diverse product models. It ensures smooth transitions between batches without frequent manual intervention. - Reduces Thermal and Mechanical Shock
Controlled board transfer prevents sudden movement while PCBs are still warm. This is critical for maintaining solder joint reliability in appliance control electronics. - Optimized for Continuous Operation
Designed for long production runs, the system maintains consistent unloading performance. It supports mass production of smart home devices without sacrificing stability. - Enhances Operator Safety and Ergonomics
Automated unloading reduces direct contact with hot PCBs. This lowers workplace risk and improves overall shop-floor safety. - Adapts to Different Line Configurations
The integrated track system allows flexible installation with various wave soldering machines. It fits easily into existing smart appliance SMT and THT hybrid lines. - Improves Production Line Organization
By delivering boards in an orderly sequence, the YSU-350 simplifies downstream handling. This improves efficiency in inspection, testing, and final assembly processes.
Specifications
| Model | YSU-350 | YSU-450 |
| Dimension(mm) | 2200*485*1400 | 2200*600*1400 |
| PCB Size(mm) | 50*50-445*350 | 50*50-450*450 |
| Speed | 0-5m/min Adjustable | |
| Power Supply | AC 2P 110V/220V; Max 100VA | |
| PCB Thickness | 0.6-5mm | |
| Transport Height | Input 1100-1350mm (Adiustable) | |
| Output 700-950 mm (Adjustable) | ||
| Transport Direction | From left to right or right to left | |
| Weight(KG) | 80 | 85 |
